Item #ASR001

WiiM Mini

Wireless Audio Streamer with Hi-Res Audio and Multi-Room Stereo
Item #ASR001

WiiM Mini

Wireless Audio Streamer with Hi-Res Audio and Multi-Room Stereo
$99.00
In Stock: Free 2-Day Shipping
Contact Us

Overview

Turn any audio gear smart. WiiM Mini is the ultimate music streamer with AirPlay 2, DLNA, Spotify Connect, TIDAL Connect, lossless audio, Alexa and multiroom audio. It turns your existing stereo system into a smart one, so you can play all your favorite music from your music app, the WiiM App or your voice by using Alexa or Siri.

Watch our Comparison

Super Easy Setup

WiiM Mini will pop up automatically in the WiiM Home app. Follow the in-app guide and start streaming music in less than 2 minutes.

Stream Hi-Res Audio up to 192 kHz/24 bit

WiiM Mini supports up to 192kHz, 24-bit audio output. That's the same as an artist's recording in the studio. The integrated TI stereo DAC provides high-quality analog audio output with 106-dB SNR, dynamic range, and -92dB THD+N performance.

All Your Content in One App

WiiM supports many popular music streaming services in their WiiM Home app with more to come. Or connect to your NAS or local files to stream your favorite music.

Spotify Connect

Use your Spotify app as your remote to control music playback to your WiiM Mini. Spotify Connect works for both Spotify Free and Premium users.

Play Music Everywhere with Multi-Room Audio

Building a wireless multiroom system has never been easier. Group WiiM Mini with other AirPlay 2 speakers, Alexa-enabled devices, or another WiiM Minis to have a multi-room/synchronized audio experience.

Automate Your Routines

Make your life easier by automating your routines. For your sleeping and wake-up routines, create a routine to wake up or fall asleep to your favorite music, station, or podcasts. Or, use your Alexa to create routines.

Works with Siri and Alexa

Connect WiiM Mini to your existing Echo or HomePod and use Siri or Alexa to select music,control playback volume, and more.

What's in the Box:

  • Type-C Cable x1
  • 3.5mm male to male Cable x1
  • 3.5mm Aux to RCA Cable x1
  • Digital Optical Audio/Toslink Cable x1
  • Power adapter x1

Details & Specs

WiiM Mini Specs:

Model WiiM Mini
Dimensions 2.7" x 2.7" x 0.9"
Weight 1.4oz
Audio Codec MP3, AAC, ALAC, APE, FLAC, WAV, WMA, OGG
Wi - Fi Dual band Wi-Fi supports 802.11 a/b/g/n/ac 2.4 GHz and 5 GHz network
Bluetooth Bluetooth 5.2, SBC and AAC codec, BT receiver and transmitter (with SW update)
Line in 1Vrms
Line in to Line out

  • Power Output=2Vrms
  • THD+N Ratio=0.009%
  • SNR=102dB
  • Crosstalk=-106dB
  • Dynamic Range=96dB

BT in to Line out

  • Power Output=2Vrms
  • THD+N Ratio=0.009%
  • SNR=102dB
  • Crosstalk=-106dB
  • Dynamic Range=96dB

Line in to SPDIF out

  • Power Output=-3dBFS
  • THD+N Ratio=0.005%
  • SNR=102dB
  • Crosstalk=-103dB
  • Dynamic Range=97dB

BT in to SPDIF out

  • Power Output=0dBFS
  • THD+N Ratio=0.005%
  • SNR=297dB
  • Crosstalk=-364dB
  • Dynamic Range=213dB

Power Supply 5V,1A
LED Three color status LED - Red, Green and White
Button Capacitive touch - Play/Pause, Volume+, Volume-

WiiM Product Differences:

Model WiiM Mini WiiM Pro WiiM Pro Plus WiiM Amp
Main Purpose Connected to amplifier or powered speaker for streaming Connected to amplifier or powered speaker for streaming Connected to amplifier or powered speaker for streaming Connected to passive speaker for streaming
Audio Amplification No No No Yes (TI TPA3255 Amplifier IC)
Pair with a Sub No No No Yes
USB Port (Storage/Audio Out) No No No Yes
Ethernet No Yes Yes Yes
DAC IC TI PCM 5121 TI PCM 5121 AKM 4493SEQ ESS 9018 K2M
Analog Out SNR 106 dB 106 dB 121 dB 98 dB
THD+N (Analog Out) No92dB (0.0025%) No92dB (0.0025%) No113dB (0.00023%) No92dB (0.002%)
Analog Input (ADC) Fixed 48k, 16 bit Fixed 48k, 16 bit Up to 192k, 24 bit Up to 192k, 24 bit
Chromecast Audio No Yes Yes Yes
Group with Nest speakers and Display No Yes Yes Yes
Group with Echo speakers and Display Yes Yes Yes Yes
Alexa Multiroom with UHD No Yes Yes Yes
Group with HomePods Yes Yes Yes Yes
Works with Alexa Yes Yes Yes Yes
Works with Google No Yes Yes Yes
Works with Siri Yes Yes Yes Yes
Group with WiiM or Linkplay devices Yes Yes Yes Yes
AirPlay 2 Yes Yes Yes Yes
AirPlay Cast No Yes Yes Yes
2-Way Bluetooth Yes Yes Yes Yes
Roon Ready No Yes Yes Yes
DLNA Yes Yes Yes Yes
Spotify Connect & TIDAL Connect Yes Yes Yes Yes
Gapless Playback Yes Yes Yes Yes
10-band Graphics EQ Yes Yes Yes Yes
Linkplay Music Streaming Platform Yes Yes Yes Yes
CPU Dualcore A7 Quad Core A53 Quad Core A53 Quad Core A53
DRAM 128 MB 512 MB 512 MB 512 MB
Flash 128 MB 512 MB 512 MB 512 MB
Audio Input Port AUX 3.5mm jack Line-in, Optical Line-in, Optical Stereo RCA / Optical / HDMI ARC / USB-A
Audio Output Port AUX 3.5mm jack, Optical Line-Out, Optical, Coax Line-Out, Optical, Coax HP terminals / Subwoofer
