Item #DLC-1500.4d

Theory DLC-1500.4d

1,500W 4-Channel Distribution Loudspeaker Controller with Dante
Item #DLC-1500.4d

Theory DLC-1500.4d

1,500W 4-Channel Distribution Loudspeaker Controller with Dante
$4,750.00
Call To Purchase

Overview

New Levels of Power

The DLC-1500.4d delivers a massive 3000W in a 16 pound chassis. Capable of delivering 1500W into 4 or 8-ohms from any channel pair, or 800W into 2 or 4-ohms all channels driven, this 16lb., 2U loudspeaker controller packs new levels of power into minimal rack space. If that weren’t enough, the DLC-1500.4d can drive 70V/100V hi-Z loudspeakers direct - no internal transformer required.

The DLC-1500.4d is equipped with Dante / AES67 audio-over-IP digital I/O making setting up and deploying even complex distributed audio systems painless and bullet-proof. No bulky analog audio cables are required.

The DLC-1500.4d can drive up to 16 Theory 16-ohm loudspeakers in Lo-Z mode, or over 300 (!) in Hi-Z mode. You read that right, 300+ Theory speakers at 7.5W each.

The DLC loudspeaker controllers from Theory can be configured via its on-board web interface accessible via wired Ethernet, or via its on-board Wifi access point and includes matrix mixing, priority audio routing and ducking, parametric EQ, delay, gain and limiter DSP objects to make system optimization easy.

Full API and modules for AMX, Control4, Crestron, Crestron Home, ELAN, Q-SYS, and RTI available.

Details & Specs

Model Theory DLC-1500.4d
Description 4-Channel Amplified Distribution Loudspeaker Controller with Dante & AES67
2U Chassis
IP Control via Ethernet or Built-In WiFi Access Point
LoZ BTL Mode
Operation LoZ and HiZ (70V/100V) Operation
Inputs 4 x Balanced Analog Audio
4 x RCA Unbalanced Analog Audio
1 x S/PDIF Digital Audio
4 x Dante / AES67 Digital Audio
Outputs 4 x Speaker Outputs
S/PDIF Digital Audio
4 x Dante / AES67 Digital Audio
Trigger +12VDC
Audio Operation 48kHz/24-bit
On-Board DSP 48kHz/32-bit
DSP Features Loudspeaker Processing For All Theory Models
Input Matrix Mixer
5 Parametric Input EQ Filters
Input Trim
Stereo/Mono Inputs and Zones
Signal Routing Including Priority Automatic Routing
Audio Ducking
10 Parametric Output EQ Filters
Crossovers
Gain
Delay
Polarity
Peak and RMS Limiters
Frequency Response 20Hz-20kHz, +/-0.25dB
Power Output 2x 1500W (BTL) @ 100V
2x 1200W (BTL) @ 70V
4x 400W (SE) and 2x 1500W (BTL) @ 8-ohms
4x 800W (SE) and 2x 1500W (BTL) @ 4-ohms
4x 800W (SE) @ 2-ohms
Voltage Gain Variable
Input Sensitivity (selectable) +14dBu
+4dBu
-10dBV (Unbalanced RCA)
Microphone
Power Requirements Standby: <1W
(1/8 power, all ch. driven): 470W
Idle Noise(A-Wt) -78dBV
Signal to Noise Ratio >106dB
Distortion (1kHz, 1dB below max output) <0.02%
AC Operation 100V-240VAC, 50-60Hz
Terminals Eurblock Connectors
Outdoor Capability Indoor Use Only
Mounting Points Rack Mount Ears Included
Finish Matte Black
Dimensions 3.50" H x 19" W x 12.6" D (89mm H x 483mm W x 320mm D)
Net Weight 16.8 lbs. (7.62 kg)
Included Accessories Rack Ears
