Revel Concerta2 S16

2-way 6.5" On-Wall Loudspeaker - Each

Revel Concerta2 S16

2-way 6.5" On-Wall Loudspeaker - Each
$495.00
Select Color Options:

Contact Us

Overview

The Concerta2 S16 on-wall loudspeaker was designed to deliver outstanding accuracy over a remarkably wide frequency range. The 2-way 6.5” on-wall loudspeaker has the ability to provide performance worthy of the most demanding entertainment systems.

Sold individually.

The S16 is a true full range 2-way 6.5” on-wall loudspeaker that was designed to integrate the entire system’s sound into a spacious, enveloping surround-sound environment. By truly being a multi-use speaker the S16 is capable of acting as a LCR or surround sound speaker depending on the specific application. It will deliver an impressive combination of wide frequency range, uncompressed dynamic range and low distortion across the entire audible spectrum.

High frequency response is supported by 1 inch aluminum dome tweeters that were derived from Revel’s Performa3 series. Low/Mid range frequency response is supported by 6.5” Aluminum cone woofers featuring low-distortion motor-structures for greater clarity and accuracy with improved sensitivity and output capability.

The patented wave guide design improves tweeter to woofer blend and significantly improves off-axis response for consistent performance over a wide listening area. In doing this we sacrificed no details by making sure no fasteners were visible allowing the speaker to show enhancing smooth lines of the cabinet and magnetically attached grilles. To finish the enclosure, we selected high gloss black and white finishes to highlight the features of this beautiful speaker.

S16 Highlights

  • Derived from Revel’s award-winning Performa3 Series Loudspeakers
  • 6.5"deep anodized aluminum cone woofers
  • 1" Aluminum Tweeter
  • Fourth generation Acoustic Lens waveguides
  • Computer optimized driver positioning and network integration
  • No visible fasteners on the front, top or side panels
  • Magnetic grilles with brushed metallic logos
  • High-gloss Black and High-gloss White painted finishes

Details & Specs

Model Concerta2 S16
Crossover Frequencies 1.8kHz
Enclosure Type Sealed
High-frequency Driver Components 1" Aluminum Tweeter with Acoustic Lens Waveguide
Nominal Impedance 6 Ohms
Input Connections Five-way binding posts
Low Frequency Extension 70Hz, 58Hz, 43Hz (-3 dB, -6 dB, -10 dB)
Low-frequency Driver Components 6.5" Aluminum Cone Woofer
Recommended Amplifier Power 30-120W
Sensitivity 90dB (2.83V @ 1M)
Dimensions 14.75 x 13.3 x 5.5 Inches - Including Feet
Weight 14 lbs
