Item #R10S

Perlisten Audio R10s

Single Driver 10" Subwoofer
Item #R10S

Perlisten Audio R10s

Single Driver 10" Subwoofer
$1,995.00
Call To Purchase

Overview

This powerful speaker boasts advanced technologies and high-quality components that ensure a stunning audio performance that enhances your overall movie-watching experience.

TINY FRAME, MIGHTY BASS

R-Series subs – Trickle down technology from their flagship D-Series, Perlisten has developed a lineup of single driver-based subwoofers. Ground up drivers developed by their team of engineers. Glass fiber composite diaphragms, multiple aluminum shorting rings, massive magnets, multi-layer Nomex spiders and lightweight aluminum voice coil wire are the key ingredients – Proprietary nonlinear modeling techniques allow us to simulate all these components and then optimize for real world driver performance – free air and in box. Further refinement is done with the aid of Perlisten's Klippel laser measurement system to dial things in. Powered by their new 1.0kW amplifier, throttled back to 750W here to match the 10” driver, all functions and safeties are controlled by a 48-bit data bath DSP and 32-bit ARM M4 Cortex processor, able to react in microseconds ensuring sonic accuracy. All R-Series subs share Perlisten's 2.4” LCD touchscreen display and ability to control advanced settings using the Perlisten app.

Details & Specs

Model R10s
Alignment Acoustic suspension
Amplifier 750W rms
Display Interface 2.4" LCD color touchscreen
App iOS and Android
Processor 32-bit ARM Cortex M4, double precision floating point math
DSP Engine Ti DSP 48-bit data paths
Driver compliment
  • 250mm, Glass fiber diaphragm
  • +/-20.0mm linear excursion
Reference sensitivity 88dB /150mV/ 1.0m
THX EQ 20-301Hz (-6dB) / 16-380Hz (-10dB)
Boost (Large Room) EQ 16-301Hz (-6dB) / 14-380Hz (-10dB)
Cut (Small Room) EQ 25-301Hz (-6dB) / 19-380Hz (-10dB)
Inputs
  • (1) Balanced XLR
  • (1) Unbalanced RCA
Outputs
  • (1) Balanced XLR unbuffered
  • (1) Unbalanced RCA unbuffered
Parametric EQ 10-Band PEQ with 3 user presets
Low Pass filter Bypass, 30-160Hz, slope 6,12,18,24dB/oct
Phase Variable 0-270
Polarity Normal / inverted
Configurable Auto turn-on and 12v Trigger XLR, RCA
Dimensions (HxWxD)
  • 388 x 340 x 380mm
  • 15.3 x 13.4 x 15.0"
Weight 21.0 kg (46.2 lbs.)
Available finishes Satin black
