Item #CW280IDC

Monitor Audio W280-IDC

Series 200 In-Wall Speaker
Item #CW280IDC

Monitor Audio W280-IDC

Series 200 In-Wall Speaker
$650.00
Special Order: Ships Free From Manufacturer
Contact Us

Overview

Features an 8-inch C-CAM bass driver and a pivoting IDC module, housing a 4-inch C-CAM RST inverted midrange driver and a 1-inch C-CAM Gold Dome tweeter.

True 3-way design provides rich midrange detail, higher system output, greater power handling, and superior vocal intelligibility and sound localization.

Optimum imaging and set-up are established via the pivoting IDC, high frequency (+3 dB /0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.

Details & Specs

  • Frequency Response - 45 Hz – 30 kHz
  • Nominal Impedance - 6 ohms
  • Sensitivity (1W@1M) - 90 dB
  • Maximum SPL - 111.6 dBA
  • Power Handling (RMS) - 150 W
  • Recommended Amplifier Requirements - 30 – 120 W
  • Drive Unit Complement -
    • 8" C-CAM cone bass driver, pivoting IDC module housing
    • 4" C-CAM RST inverted midrange driver
    • 1" C-CAM Gold Dome tweeter
  • Adjustment Controls -
    • HF Level Switch (+3 dB / 0 dB / -3 dB)
    • Boundary Compensation Switch
  • Overall Diameter (Including Grille) - 441 x 288 mm (173/8 x 115/16")
  • Overall Depth (Including Grille) - 104 mm (41/8")
  • Mounting Depth - 100 mm (315/16")
  • Cut-Out Hole Diameter - 387 x 234 mm (151/4" x 93/16")
  • Fixing Type - 6 position Tri-Grip dog fixings
  • Construction Material - Mineral filled ABS, RoHS compliant
  • Weight - 3.6 kg (7 lb 14 oz)
  • Pre-Construction Bracket - WB8 Pre-Construction Bracket (Green)
  • Back Box - WCBOX-L
