Item #CW165

Monitor Audio W165

Series 100 In-Wall Speaker
Item #CW165

Monitor Audio W165

Series 100 In-Wall Speaker
$320.00
Special Order: Ships Free From Manufacturer
Contact Us

Overview

Incorporating a 6 1/2" MMP II bass driver with Monitor Audio’s signature C-CAM Gold Dome tweeter to provide high-performance sound, ease-of-drive, and wide frequency response and dispersion.

Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.

Details & Specs

  • Frequency Response - 60 Hz – 25 kHz
  • Nominal Impedance - 6 ohms
  • Sensitivity (1W@1M) - 88.5 dB
  • Maximum SPL - 107.4 dBA
  • Power Handling (RMS) - 65 W
  • Recommended Amplifier Requirements - 20 – 65 W
  • Drive Unit Complement -
    • 6 1/2" MMP II cone bass driver
    • 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls - HF Level Switch (+3 dB / 0 dB / -3 dB)
  • Overall Diameter (Including Grille) - 370 x 250 mm (14 9/16 x 9 13/16")
  • Overall Depth (Including Grille) - 96 mm (3 3/4")
  • Mounting Depth - 92 mm (3 5/8")
  • Cut-Out Hole Diameter - 332 x 213 mm (13 1/16 x 8 3/8")
  • Fixing Type - 6 position Tri-Grip dog fixings
  • Construction Material - Mineral filled ABS, RoHS compliant
  • Weight - 2.21 kg (4 lb 14 oz)
  • Pre-Construction Bracket - WB6 Pre-Construction Bracket (Purple)
