Monitor Audio Bronze W10 6G

Subwoofer - Black

Monitor Audio Bronze W10 6G

Subwoofer - Black
Was $975.00 From $729.98
Save $245.02
Select Color Options:

Contact Us

Overview

If you love deep and refined bass notes, the Bronze W10 is a must-have addition to your speaker set-up as every soundscape is effortlessly reinforced by Monitor Audio's beautifully designed subwoofer.

The High Notes

C-CAM Driver Technology

Monitor uses a space-age technique to coat the speaker drivers with a ceramic material that makes them stiffer and less prone to distortion. Plus the look this gives sets them apart.

Great Soundstage and Fun To Listen To

Bronze speakers have always been a great value, but these take it to the next level. They are just flat-out fun to listen to with their punchy sound and room-filling soundstage.

Beautiful British Design

Pull the grills off and enjoy the look of their special tweeter waveguide and the C-CAM drivers. This is one cool-looking speaker collection.

The Bronze W10’s long-throw 10" C-CAM subwoofer driver combines with the 10" auxiliary bass radiator to bring a vivid realism to any performance.

Monitor Audio's engineers have acoustically improved the driver and bass radiator by reducing the moving masses and tuning the compliances in the system to improve the transient response - kick drums and explosions now have much more punch and precision. Reduced moving mass and improved rubber feet allows more energy to be transmitted directly into the room rather than being lost through mechanical vibrations through the floor and walls.

The Bronze W10 is a stunning addition to any room.

Key Features

  • Long-throw 10" (250 mm) driver featuring ‘dished’ C-CAM 10" (250 mm) flat-panel
  • Auxiliary Bass Radiator (ABR) positioned underneath the unit Class D amplifier with high current Switch Mode Power Supply (SMPSU)

Details & Specs

  • System Format - Long-throw 10" driver featuring ‘dished’ C-CAM cone. 10" flat panel ABR (Auxiliary Bass Radiator). 18 mm M.D.F. internally braced construction
  • Lower Frequency Limit -
    • -3 dB @ 33 Hz / -10 dB @ 28 Hz (Free Field)
    • Default preset: Music, -3 dB @ 29 Hz / -10 dB @ 25 Hz (In Room)
  • Upper Frequency Limit - -6 dB @ 150 Hz
  • Drive Unit Complement - 1 x 250 mm (10") C-CAM subwoofer driver featuring a 2" long-throw voice coil
  • Linear Driver Excursion - 17 mm peak to peak
  • Amplifier Output - 220 W
  • Amplifier Classification - Class D with high current Switch mode power supply (SMPSU)
  • Phase Control - 0 Degrees & 180 Degree pure Invert
  • Low Pass Filter Alignment - 4th order (24 dB/Octave), from 50 Hz to 120 Hz
  • Equalization DSP - 3 pre-set modes: Music, Movie, Impact
  • Auto Sensing Line Level - >3mV. Auto Standby feature after 20 mins
  • Audio Input/Outputs - LFE unbalanced input RCA Stereo unbalanced inputs RCA
  • Input Impedance - 20 kOhms input impedance
  • 12 V Trigger - 3.5 mm mono mini-jack. 6 V threshold
  • Electrical Certifications - CE / CB / ETL / Fcc / CCC / ErP (Energy-saving compliant)
  • Mains Input Voltage - 110 – 120 Vac 50 – 60 Hz / 220 – 240 Vac 50 – 60 Hz (Manually selected)
  • Power Consumption Maximum - 300 W, Standby <0.5 W (ErP compliance)
  • Fuse Type - 20 mm T4AL 250 VAC
  • External Dimensions (Including Amp, Drivers and Terminals (H x W x D)) - 321 x 321 x 364 mm (125/8 x 125/8 x 145/16")
  • External Dimensions (Including Amp, Drivers, Terminals and Feet (H x W x D)) - 366.5 x 321 x 364 mm (147/16 x 125/8 x 145/16")
  • Weight (unpacked) - 13.4 kg (29 lb 9 oz)
