Item #SA-600W

JL Audio Fathom SA-600W

600W Subwoofer Amplifier & Processor
Item #SA-600W

JL Audio Fathom SA-600W

600W Subwoofer Amplifier & Processor
$1,350.00
Available In-Store

Overview

Equipped with flexible features and a robust power amplifier section, the Fathom® SA-600W is an ideal choice to drive a custom subwoofer system in home theater and home audio systems. The full set of Fathom® signal processing features is included, along with additional DSP features, managed through an intuitively designed onboard interface. With its precisely engineered switching power supply and proprietary Class-D amplifier topology, the SA-600W is capable of efficiently delivering up to 600 watts of continuous power.

The SA-600W includes the following features:

  • Pristine, stereo audio circuit pathways used throughout
  • Intuitive interface with LCD display provides detailed control of onboard settings and functions
  • On-board, 2-way active crossover (12/24 dB per octave), capable of supporting a stereo system with a low-pass filtered subwoofer output and high-pass filtered line outputs to feed the main speakers’ amplifier
  • Built-in, optimized equalizer curves for use with JL Audio subwoofers systems
  • Fixed or variable level control options
  • Selectable polarity control (0 or 180 degrees) to optimize subwoofer integration
  • Programmable delay controls for the SA-600W’s subwoofer outputs and line outputs.
  • E.L.F. (Extreme Low Frequency) trim applies equalizer cut or boost at 25 Hz (-12 to + 3 dB) to tailor a subwoofer’s response for a particular room.
  • D.A.R.O. (Digital Automatic Room Optimization) automatically measures and corrects in-room response to optimize low-frequency performance (requires optional JL Audio calibration microphone – CAL-MIC1 – sold separately)
  • Three-band parametric equalizer with configurable center frequency, Q and gain, to further optimize subwoofer system response
  • Grounded or Isolated input mode options for quiet, noise-free performance
  • Stereo, high-level inputs accept direct connection from amplified receiver outputs when no line-level signal is available.
  • Wireless signal connectivity is available via the optional JLink™ Transmitter/Receiver system (JLink™ TRX – sold separately).
  • Automatic turn-on options via signal sensing or 12V trigger. 12V input and output triggers to control additional SA-600Ws or peripheral equipment
  • Front-mounted USB port and DFU button provides easy access to update firmware.
  • Versatile mounting options for table-top setups or rack-mount installations.

Details & Specs

General

  • Amplifier Power:
    • 600 W x 1 at 3 ohms
    • 450 W x 1 at 4 ohms
    • 300 W x 1 at 6 ohms
    • 225 W x 1 at 8 ohms
  • Power Mode(s): Off, On or Automatic (Signal-Sensing or 12V Trigger)
  • 12V Trigger Output Capacity: 150 mA (1/8-inch/3.5mm mini jack)

Signal Processing

  • Unbalanced Inputs: Stereo or Mono (two RCA jacks - Input Impedance of 50k Ohms)
  • Speaker/High-Level Inputs: Stereo or Mono (removable plug - Input Impedance of 4.4k Ohms)
  • Input Grounding: Isolated or Grounded
  • Level Control: Reference (fixed gain) or Variable from -50dB to +15dB over reference gain (0.5 dB increments)
  • Filter Mode(s): Low-Pass, with tracking High-Pass Outputs
  • Filter Slope(s): 12/24 dB/octave
  • Filter Frequency Range: 30 Hz - 130.1 Hz
  • Filter Defeat Function: Yes
  • Polarity: 0 or 180 degrees
  • Delay (Phase): Variable from 0 – 25 ms
(0.1 ms increments, Sub and HP outputs)
  • Extreme Low Frequency (E.L.F.) Trim: Variable, -12 dB to +3 dB at 25 Hz (0.5 dB increments)
  • Line Outputs: Stereo or Mono (two RCA jacks - Pass-Through or High-Pass)
  • Subwoofer Outputs: Neutrik speakOn® 2-Pole Connectors
(uses Neutrik part: NL2FX)
  • Calibration Mode: Digital Automatic Room Optimization (D.A.R.O.), requires microphone (sold separately)
  • Equalizer Bands: 3
  • Equalizer Frequency Range: 20 to 160 Hz (1 Hz increments)
  • Equalizer Gain Range: -12 dB to +12 dB (0.2 dB increments)
  • Equalizer Q Range: 0.7 to 5.0 (0.1 increments)

Dimensions

  • H x W x D: 1.75 x 16.84 x 13.63" (44 x 428 x 346 mm)
  • Net Weight: 13.5 lb / 6.12 kg
