Item #f212v2-GLOSS

JL Audio f212v2-GLOSS

Dual 12-inch Powered Subwoofer
Item #f212v2-GLOSS

JL Audio f212v2-GLOSS

Dual 12-inch Powered Subwoofer
$10,000.00
Available In-Store

Overview

Details & Specs

General Specifications

Enclosure Type: Sealed


Enclosure Finish: Black Gloss


Frequency Response (Anechoic): 20 - 97 Hz (±1.5dB) -3 dB at 19 Hz / 110 Hz -10 dB at 15 Hz / 157 Hz


Effective Piston Area (Sd): 168 sq in / 0.1084 sq m


Effective Displacement: 574 cu in / 9.4 L


Amplifier Power: 3.6 kW RMS short-term


Power Mode(s): Off, On or Automatic (Signal-Sensing)


Light Modes: Off, On or Dim

Signal Processing


Unbalanced Inputs: Stereo or Mono (two RCA jacks)


Balanced Inputs: Stereo or Mono (two female XLR jacks)


Speaker/High-Level Inputs: N/A


Input Grounding: Isolated or Grounded


Input Modes: Master or Slave


Level Control: Reference (fixed gain) or Variable, from full mute to +15dB over reference gain


Filter Mode(s): Low-Pass


Filter Slope(s): 12/24 dB/octave


Filter Frequency Range: 30 Hz - 130 Hz


Filter Defeat Function: Yes


Polarity: 0 or 180 degrees


Phase: Variable, 0 - 280 degrees


Extreme Low Frequency (E.L.F.) Trim: Variable, -12 dB to +3 dB at 25 Hz


Line Outputs: N/A


Output to Slave: Balanced (one male XLR jack)


Calibration Mode: Digital Automatic Room Optimization (D.A.R.O.), incudes laboratory-grade microphone

Physical Specifications


Width (W) 14.92 in / 379 mm
Height (H) 31.96 in / 812 mm
Depth (D) 20.39 in / 518 mm
Net Weight 224 lb / 102 kg
Note: Height dimensions include feet.
