JBL Summit Makalu

Floorstanding Loudspeaker - Ebony High Gloss - Pair

JBL Summit Makalu

Floorstanding Loudspeaker - Ebony High Gloss - Pair
$44,999.90
Select Color:

Available In-Store
Contact Us

Overview

Summit Makalu is the flagship floorstanding loudspeaker, engineered for listeners who demand absolute scale, power, and refinement. Its advanced three-way design combines a 3-inch D2 compression driver with HDI horn, an 8-inch mid-bass driver, and a commanding 12-inch woofer. The MultiCap crossover and dual rear-ported enclosure deliver thunderous low-frequency authority with pristine clarity. Summit Makalu sets a new benchmark for reference-level performance and luxury design.
Watch our Comparison

Introducing

The Summit Makalu, a floorstanding loudspeaker built for the discerning music enthusiast. It features a newly designed complement of drivers starting with JBL’s D2830K 3-inch (75mm) dual-diaphragm, dual-motor compression driver mated to a large format Sonoglass High-Definition Imaging (HDI) horn. Anchoring the sound foundation of Summit Makalu are an 8-inch (200mm) cast-frame mid-bass driver and a 12-inch (300mm) cast-frame woofer. Both drivers utilize a triple-layer Hybrid Carbon Cellulose Composite Cone (HC4), a design made from a proprietary formula of carbon-fiber and pure-pulp front and rear surfaces, sandwiched with an internal core of closed-cell foam. This hybrid cone design provides the proper stiffness, overall mass, and structure to deliver high-output, low distortion, and high-power handling.

Controlling how the signal is distributed to each of the drivers in Summit Makalu is a MultiCap crossover network with single-wire and bi-amp/bi-wire connectivity. By replacing traditional large capacitors with an increased number of smaller capacitors, this design results in lower ESR (Electro-Static Resistance) and less energy lost in mechanical movement. All of which results in greater signal throughput to the drivers, increased power handling, enhanced dynamics, ultra-low distortion, and exceptional clarity. All drivers and crossover components are housed in a beautifully engineered cabinet featuring internally offset multi-braced and damped curved-wall construction to minimize internal cabinet standing waves. Enclosures are offered in a choice of a high-gloss painted black finish with Summit platinum accents or high-gloss ebony wood veneer finish with Summit gold accents.

Highlights

  • 3-inch (75mm) Dual-diaphragm, Dual-motor High-Frequency Compression Driver mated to a custom High-Definition Imaging (HDI) Sonoglass Acoustic Horn
  • 8-inch (200mm) Cast-frame, Triple-layer Hybrid Carbon Cellulose Composite Cone (HC4) Mid-bass with Accordion-Edge Surround
  • 12-inch (300mm) Cast-frame, Triple-layer Hybrid Carbon Cellulose Composite Cone (HC4) Woofer with Half-Forward-Roll Surround
  • MultiCap™ Crossover Network with Single-wire and Bi-Amp/Bi-Wire Connectivity
  • Frequency Response: 20Hz–34kHz (-10dB) / 23Hz–33kHz (-6dB)
  • Finely Crafted and Beautifully Detailed Enclosure with Carbon Fiber Baffle Trim
  • Soft-curved Cabinet Walls with Heavily Braced and Dampened Construction from sustainably-sourced engineered wood
  • JBL/IsoAcoustics Adjustable Acoustic Isolation Feet
  • Luxurious High Gloss Finishes with Summit Platinum or Summit Gold detailing
JBL Summit Makalu Floorstanding Loudspeaker

Details & Specs

Model JBL Summit Makalu
Description 3-Way, 12-inch (300mm) Floorstanding Reference Loudspeaker
High Frequency Control High-Definition Imaging (HDI) Sonoglass Acoustic Horn
High Frequency Transducer D2830K; Dual 3-inch (75mm) Annular Ring Teonex Diaphragms, Dual-motor D2 Compression Driver Mated to the Summit Makalu High-Definition Imaging (HDI) Horn
Mid-Bass Transducer JMW200SG; 8-inch (200mm), Triple-layer Hybrid Carbon Cellulose Composite Cone (HC4) with Dual-Inverted Spiders, a 2.5-inch Voice Coil, Underhung Neodymium Motor, Cast Aluminum Frame, and Treated-Cloth Accordion-Edge Surround
Low Frequency Transducer JW300SC; 12-inch (300mm), Triple-layer Hybrid Carbon Cellulose Composite Cone (HC4) with Dual Inverted Spiders, 3-inch Voice Coil, Ferrite Motor, Cast Aluminum Frame, Half-Forward-Roll Surround
Sensitivity (2.83V @ 1m) 88 dB
Recommended Power 25 – 300 Watts RMS
Maximum SPL 113 dB
Frequency Response 20Hz – 34kHz (-10dB on-axis)
23Hz – 33kHz (-6dB on-axis)
Impedance 4 Ohms (Nominal)
3.5 Ohms (Minimum @ 79Hz)
Crossover 285Hz / 1100Hz / Series MultiCap / Acoustically Symmetric 3rd and 4th Order 3-way
Internal Wiring Ohno-Continuous-Cast (OCC) Long-Crystal Oxygen-Free Silver-Plated Copper Wire
Controls Bi-amp / Bi-wire Capable with 2-Pairs of Binding Posts
Input Type Rhodium-Plated, Silver-Coated, Oxygen-Free, Pure Copper Core Binding Posts with a Chrome-Plated Brass Carbon-Fiber Wrapped Shell and Nylon / Glass-fiber Insulators (2 pairs)
Enclosure Type Internally Offset Multi-Braced & Dampened Curved-Wall Made from Sustainably-Sourced Engineered Wood with Multi-Component Lining
Enclosure Tuning Dual Rear-Flared Bass Ports
Enclosure Finish Options Black High Gloss (BG)
Ebony Veneer with High Gloss (EG)
Net Dimensions with grille (H x W x D) 43.4" x 18.3" x 15.5" (1102.3mm x 464.3mm x 393.0mm)
Weight 152.6 lbs (69.2kg)
Shipping Dimensions 51.1" x 27.4" x 25.0" (1298.0mm x 695.0mm x 636.0mm)
Shipping Weight 177.3 lbs (80.4kg)
