JBL SDP-80

36 Channel Immersive Audio Processor

JBL SDP-80

36 Channel Immersive Audio Processor
$42,000.00
Now Available For Pre-Order

Overview

The JBL Synthesis SDP-80 opens the way to a whole new generation of luxury home cinema processors, designed for ultimate performance and sustainability within the fast-moving home theater entertainment industry.

With 36-channels of processing, the SDP-80 offers full support for Dolby ATMOS, DTS:X, and Auro-3D immersive audio formats. Powerful Trinnov Optimizer room EQ features JBL Synthesis performance enhancements and provides for incredibly accurate system tuning.

A full suite of digital and analog connectivity is included along with HDMI 2.1 AV switching capable of handling higher resolution audio and video content at data rates up to 48Gbps for video up to 8K resolution at 60 frames per second with HDR, or 4K up to 120 frames per second with HDR. Full external control allows for complete and easy system integration.

Key Features

  • 36 channels of native high-resolution digital processing for the most sophisticated high-channel count flagship JBL Synthesis systems with best-in-class sound quality.
  • Pre-configured for benchmarked JBL Synthesis performance with the Harman Target and JBL Synthesis loudspeaker EQ files.
  • Audiophile feature set including high-resolution playback, and key features including HDMI 2.1 with HDCP 2.3 and HDR up to 48Gbps, Dolby Atmos and Dolby Vision, DTS:X Pro and AURO-3D immersive audio processing, Trinnov Optimizer for in-room speaker optimization, and Roon Ready for hi-resolution music streaming.

Details & Specs

Model SDP-80
Video Connections
Inputs 8x HDMI 2.1/HDCP 2.3, up to 48Gbps for video up to 8K resolution at 60 frames per second with HDR, or 4K up to 120 frames per second with HDR
Outputs 2x HDMI 2.1 with HDCP 2.3
1x PC (VGA, DVI, HDMI)
Audio Connections
Analog Audio Inputs 2 x XLR stereo
3 x RCA stereo
1 x 8-ch RCA multichannel
1 x 3D Microphone
Digital Audio Inputs 8 x HDMI multichannel
1 x AES3 DB25 (8 or 16-channels) DCI-compliant
2 x AES/EBU XLR stereo
4 x S/PDIF Coaxial 7.1 PCM
4 x S/PDIF Optical 7.1 PCM
Analog Audio Outputs 16 x XLR multichannel
4 x Balanced DB25 (channels 1-32)
1 x RCA stereo
Digital Audio Outputs 2 x HDMI multichannel
Roon Ready via Ethernet
1 x AES3 DB25 (8 or 16-channels)
1 x AES/EBU XLR stereo
1 x S/PDIF Coaxial stereo
1 x S/PDIF Optical stereo
1 x AML Extension Link RJ45
PC Connections
Video Outputs 1 x HDMI
1 x DVI
1 x VGA
USB Ports 2 x USB 3.0
2 x USB 2.0
Ethernet 1 x RJ45 Gigabit
Wi-Fi Onboard
Controllers PS/2 Keyboard and Mouse
Communications and Control
Remote Control IR Remote Control Included
12V Trigger Input/Output
iOS and Android Apps Available
Web-based UI
Network Control VNC Remote Control from Laptop/PC, Tablet, or Smartphone
IP Control (AMX,Crestron, and Savant Modules Available)
Electrical Characteristics
Power Supply 110VAC 60Hz or 220VAC 50/60Hz
Power Consumption 0.5W standby (EuP compliant) / 100W/450mA Maximum
Physical Characteristics
Chassis 3.5U
Dimensions (H x W x D)n 6.1" x 16.9" x 15.9"
155mm x 430mm x 405mm
Weight 30.8 lb
14.5kg
