Item #DRX3.4

Integra DRX 3.4

Integra DRX 3.4 9.2-Channel Network Home Theater Receiver
Item #DRX3.4

Integra DRX 3.4

Integra DRX 3.4 9.2-Channel Network Home Theater Receiver
$1,500.00
More on the way! Order now to reserve risk free.
Contact Us

Overview

A Perfect Blend of Features, Ready to Integrate

Just right for your living room, media room, or bespoke home theater, the DRX-3.4 has the power to drive Dolby Atmos® and DTS: X® through 9 channels of onboard amplification. 8K HDR video passthrough provides the bandwidth needed for cutting-edge visuals and gaming. DIRAC Live room correction ensures your immersive surround experience is delivered with the highest fidelity. 9.2 channel pre-outs make the DRX-3.4 perfect for updating an existing separates system to HDMI 2.1, DIRAC Live and Object-Based Surround.

DIRAC LIVE Room Correction

Considered by industry leaders in music and movie production to be the state-of-the-art digital room correction solution, Dirac Live offers professional-grade, studio-quality calibrated sound with simple, easy-to-navigate tools. The result is a home theater experience that reveals your movies, music, and games in ways you’ve never heard before. Unlock the full potential of your loudspeakers in any listening space with Dirac Live.

IMAX Enhanced

Hear the sound filmmakers intended. This IMAX Enhanced A/V receiver features DTS:X sound technology optimized for the IMAX® signature experience, reproducing the full dynamic range of IMAX theatrical sound-mixes available with digitally re-mastered IMAX Enhanced content. A pre-set IMAX Mode reproduces audio at the highest levels and delivers an unmatched IMAX sound experience. Requires a free firmware update.

Dolby Atmos Height Virtualizer

When playing any Dolby® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without the need for additional surround or height speakers.

Perfect for Custom Installation

Integra products are designed and engineered to meet the demands of leading custom installers. CI Centric features such as Web Setup, Onboard HDMI Diagnostics, and compatibility with Remote Monitoring systems like OVRC Pro and Domotz make Integra AVRs the choice of the modern integrator. Optional rack mount kits provide a clean, finished look when installed in racks and cabinets, while a unique bright white back panel facilitates connections in hard-to-reach areas.

Details & Specs

Amplifier Section

  • Power Output:
    • Front L/R: 225 W/Ch at 6 Ohms, 1 kHz, 10%, 1 Channel Driven, 100 W/Ch at 8 Ohms, 20 Hz–20 kHz, 0.08%, 2 Channels Driven, FTC
    • Dynamic Power: 250 W (3 Ohms, Front) 220 W (4 Ohms, Front) 130 W (8 Ohms, Front)
  • Input Sensitivity and Impedance: 200 mV rms/47 k-Ohms (Line/Unbalance) 3.5 mV rms/47 k-Ohms (Phono MM)
  • THD+N (Total Harmonic Distortion + Noise): 0.08% (20 Hz–20 kHz, Half Power)
  • Rated RCA Output Level and Impedance: 1 V rms/470 Ohms (Subwoofer Pre-out) 200 mV rms/470 Ohms (Zone 3/Height 2/Surround Back Pre-/Line-out)
  • Phono Overload: 70 mV (MM, 1 kHz, 0.5%)
  • Frequency Response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
  • Tone Control: ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
  • Signal-to-Noise Ratio: 106 dB (IHF-A, Line) 80 dB (IHF-A, Phono)
  • Speaker Impedance: 4 Ohms–16 Ohms

Video Section

  • Signal Level:
    • 1 Vp-p/75 Ohms Composite Video
    • 1 Vp-p/75 Ohms Component Video (Y)
    • 0.7 Vp-p/75 Ohms Component Video (Pb/Pr)

Tuner Section

  • Tuning Frequency Range: FM 87.5 MHz–107.9 MHz AM 530 kHz–1,710 kHz
  • FM/AM Preset Memory: 40 Stations

General

  • Power Supply: AC 120 V~, 60 Hz
  • Power Consumption: 750 W
  • Standby Power Consumption: 0.1 W
  • Dimensions (W x H x D): 17 1/8˝ x 6 7/8˝ x 14 13/16˝ (435 x 174 x 376.5 mm)
  • Weight: 24.3 lbs. (11.0 kg)
  • Carton Dimensions (W x H x D): 22 1/16˝ x 12˝ x 18 3/8˝ (560 x 305 x 467 mm)
  • Weight: 29.8 lbs. (13.5 kg)

Reviews

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
T
Ted
Best Value AVR at the moment

I was waiting on RZ50 until I came across this Integra model. In all practical purposes, this is really an RZ50 with 20W less power per channel. I am coming from years of Denon AVR, and I have to say DIRAC Live alone is worth the cost of entry. Just finished setting it up using the included mic and the result is absolutely astounding. I looked at Denon 3700/4700 offering and Pioneer and Onkyo models, but the Integra is the only model that comes with pre-outs under $1300. I picked up an open-box model for $950 and it looks brand new. After testing it out for a couple of days, I canceled my RZ50. Audio Advice has been fantastic in terms of their support and communication, and I will be buying more from them in the future.
