Grado Sonata3

Moving Iron Phono Cartridge - High Output
Item #Sonata3

Grado Sonata3

Moving Iron Phono Cartridge - High Output
$600.00
More on the way! Order now to reserve risk free.
Contact Us

Overview

The Platinum3 model uses Grado's specially designed elliptical diamond, and the Sonata3 model uses Grado's specially designed nude elliptical diamond.

The Platinum3 and Sonata3 models use a modified four piece OTL cantilever technology achieving a 10% tip mass reduction over the Prestige series and ultra-high purity long crystal (UHPLC) oxygen free copper wire in the coils.

Details & Specs

Body: Australian Jarrah Wood
Cantilever: Aluminum / Elliptical Diamond
Output:
High 4.0mV @5 CMV (45)
Low 1.0mV @5 CMV (45)
Inductance:
High Output 55mH
l
Low Output 6mH
Resistance:
High Output 660 ohms
Low Output 70 ohms
Input Load: 10k-47k ohms
Cartridge Weight: 9 grams
Tracking Force: 1.6-1.9 grams
Compliance: 20μm/mN
Channel Seperation: Average 30db - 10-30k Hz
Controlled Frequency Response: 10-60 KHz
Non-Sensative to Capacitative Load
Builds: High Output, Low Output, Mono
