Item #C11274K

CXN100

Network Music Streamer - Lunar Grey
Item #C11274K

CXN100

Network Music Streamer - Lunar Grey
$1,099.00
More on the way! Order now to reserve risk free.

Overview

A redesigned network music streamer features an ESS ES9028Q2M reference DAC and a fourth generation StreamMagic module for digital playback. Built with balanced XLR outputs and a large color display, it supplies adaptable audio visual solutions for an premium high resolution sound system setup.

The Cambridge Audio CXN100 network music streamer features a complete mechanical redesign, upgrading standard hardware components to form an advanced digital source for a home sound system setup. Engineered and acoustically optimized at the London headquarters, this player processes incoming files through an ESS ES9028Q2M SABRE32 reference digital to analog converter. The integrated hardware manages pulse code modulation inputs up to thirty two bit seven hundred and sixty eight kilohertz and native DSD512 signals with precision. An advanced timing filter eliminates the need for post converter filtering, simplifying the signal path to reduce jitter and distortion.

Wireless operations utilize a fourth generation StreamMagic module, providing built in support for Spotify Connect, TIDAL Connect, Qobuz, and Deezer. The internal software also handles high resolution internet radio via MPEG DASH protocols and maintains full compatibility with MQA audio files. Physical inputs include a USB Type B connection, a dedicated local USB drive port, coaxial S S/PDIF, and optical TOSLINK sockets. For wireless convenience, integrated hardware handles Chromecast, AirPlay 2, and Bluetooth 5.1 connections without external adapters.

The media player accommodates smart home integration across the household by supporting Google Home, Apple AirPlay, and Roon multiroom systems. Analog audio outputs link to external amplifiers through balanced XLR or unbalanced RCA terminals, while digital audio outputs include coaxial and optical lines. Operational functions are managed through a mobile application, a separate companion remote, or the front panel, which houses a four point seventy six inch high resolution color screen to display album artwork from a distance.

Details & Specs

Model CXN100
DAC ESS ES9028Q2M
USB AUDIO INPUT USB Type B conforms to USB Audio 2.0
DIGITAL AUDIO INPUTS USB Drive, Bluetooth (5.1), S/PDIF Coaxial, TOSLINK Optical
ANALOGUE AUDIO OUTPUTS Balanced XLR and unbalanced RCA analogue
DIGITAL AUDIO OUTPUTS S/PDIF Coaxial and TOSLINK Optical
COMPATIBILITY TOSLINK optical: 16/24bit 32-96kHz PCM, DoP64 S/PDIF coaxial: 16/24bit 32-192kHz PCM, DoP64 UPnP: up to 32bit, 768kHz Local USB media: PCM up to 32-bit 768kHz, DSD up to x512 USB audio: PCM up to 32-bit 768kHz, DSD up to x512 Bluetooth: SBC, AAC AirPlay 2, Chromecast built-in, Internet Radio, Spotify Connect, TIDAL Connect, MQA, Qobuz, Deezer, Roon Ready.
AUDIO FORMATS ALAC, WAV, FLAC, AIFF, DSD (x512), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
ETHERNET 10/100Mbit
WI-FI IEEE 802.11 ac (2.4GHz / 5GHz)
MAX POWER CONSUMPTION 30W
STANDBY POWER CONSUMPTION <0.5W (eco), <2W (network standby)
DIMENSIONS 430 x 85 x 305mm (16.9 x 3.4 x 12.2")
