Item #C11083

AXA35

Integrated Stereo Amplifier with (Built-in) Phono-Stage - Grey
Item #C11083

AXA35

Integrated Stereo Amplifier with (Built-in) Phono-Stage - Grey
$449.00
More on the way! Order now to reserve risk free.

Overview

An integrated amplifier supplies 35 Watts per channel into 8 Ohms and a built in moving magnet phono stage for direct turntable connections. Featuring tone adjustments, a headphone socket, and analog filtering, it offers excellent audio visual solutions for an entry level high fidelity sound system setup.

The Cambridge Audio AXA35 is an integrated stereo amplifier that supplies thirty five Watts per channel into eight Ohm speakers. A toroidal transformer and analog filtering help keep the signal clean. The built in moving magnet phono stage allows a turntable to connect directly, so there is no need for extra equipment when playing vinyl.

The AXA35 offers four RCA inputs for connecting different sources, plus a front panel three point five millimeter auxiliary port for extra gear. A front mounted quarter inch headphone jack sends audio straight to headphones for private listening. Bass and treble controls allow up to ten decibels of adjustment at one hundred Hertz and ten kilohertz, making it easier to tune the sound for the room. A manual balance control helps with stereo alignment. A white LED dot matrix display shows which source is active and the current volume.

The physical assembly features a minimalist metal encThe AXA35 comes in a simple metal case that measures eighty three by four hundred and thirty by three hundred and thirty millimeters. This size fits well in most audio racks or media consoles at home. The amplifier covers a frequency range from five Hertz to fifty kilohertz and keeps total harmonic distortion below zero point zero one percent at one kilohertz. Power use peaks at two hundred and sixty Watts and drops below half a Watt in standby, making it a steady base for a stereo system.

Details & Specs

Model AXA35
Power Output 35 Watts (into 8 Ohms)
THD (unweighted) <0.01% @ 1kHz, 80% of rated power <0.15% 20Hz - 20kHz, 80% of rated power
Frequency response (-3dB) 5Hz - 50kHz
S/N ratio (ref 1W) >82dB (unweighted)
Input impedances 47k ohms
Power Amp damping factor >50
Max. power consumption 260W
Bass/Treble controls Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 10kHz
Standby power consumption <0.5W
Inputs 4x RCA, 1x Phono, 1 x 3.5mm Aux input (front panel)
Outputs Speakers, Rec Out, USB 5V power
Dimensions (HxWxD) 83 x 430 x 335mm (3.3 x 16.9 x 13.2”)
