Bullet Train 5K HDMI

Active Optical HDMI Cable - 10 m

Bullet Train 5K HDMI

Active Optical HDMI Cable - 10 m
From $299.00
Select Cable Length

Contact Us

Overview

Not all HDMI cables are created equally. Bullet Train has developed HDMI cables built for mission-critical environments where stability is vital. By delivering data over Cleerline SSF fiber optics alongside copper wire, Bullet Train AOC Cables deliver 18Gbps and a high frame rate signal with much lower latency – up to 20% less than a passive copper HDMI cable. These cables are ISF (Imaging Science Foundation) Certified, the name to trust in picture quality and calibration. Bullet Train cables are highly engineered, tried, and tested to be a long-lasting part of any audio/video system.

The AOC Advantage

Some poor-quality sources fail to function adequately in distributed systems, whereby the source is traveling through several components. If you have a flawed source, you have to reduce insertion loss – which is ever-present with copper. The only way to combat it is to use a thicker gauge copper cable. Using fiber optics allows you to “fix” problem sources without using longer/thicker cables.

The signal construct is different on fiber optic cables. Fiber does not require equalization to work correctly, meaning that you are not reliant on the TV to be applying the proper length of EQ per HDMI Spec. If you have a copper cable and the TV or Sink is even on EQ stage off, you will get problems. Since fiber is not beholden to this problem – you can see better performance.

  • Input Lag – For gamers or mission-critical environments, these can reduce input lag by 20%.
  • Interference – Heavy electromagnetic places (like a rack room) can interfere with HDMI or HDBaseT. These cables are not susceptible to EMI. Meaning you are circumventing yet another potential problem.
  • Bandwidth – Each TMDS line has a dedicated piece of fiber, meaning you have four strands of fiber at 40 Gbps per lane. It’s possible to repurpose these fiber strands for future applications.
  • Size – Using fiber is the most effective way to make thin cables.
  • Power – Unlike other AOC cables that use a lot of energy for their fiber transmission, resulting in the need for additional power adapters. These cables use less energy to power the fiber technology. No more supplemental power is required.

Refresh Rate

This HDMI cable supports the HDMI 2.0 refresh rate range, which becomes extremely important as you push the limit of frames per second. Bullet Train allows the display to match the speed at which frames are traveling through the HDMI cable. This ensures the timing at these extremely minuscule measurements are displayed accurately and efficiently.

Increased Frame Rate

With HDMI 2.0 specifications, these cables can reach data rates up to 60 FPS. This allows them to more than double the standard Frame Rates seen on HDMI of 24 frames-per-second (FPS) to 60 FPS.

Color Accuracy

Bullet Train cabling comes from a family of HDMI Testing and Display Calibration, which is why they can offer Imaging Science Foundation (ISF) certification on every single cable they sell. ISF is a leader in scientifically accurate display coloring, when you run a signal through this HDMI cable you are seeing the vibrant colors the content was mastered in.

What's Inside?

Once you have a Bullet Train AOC cable, you also have four Cleerline SSF Fiber Optic strands. This fiber is ready for over 100Gbps, and you can terminate it when HDMI technology becomes outdated!

  • Step 1: Run cable
  • Step 2: Use cable for years
  • Step 3: Ten years down the line, cut off the end of the cable and you have four terminable OM2 Fiber Optic strands
  • Step 4: Using any termination kit, you can now use these fiber strands for data, A/V, control, telephone, or any signal that runs over fiber

Details & Specs

Model Bullet Train 5K Active Optical HDMI Cable
Connector 1 1 x HDMI Male
Connector 2 1 x HDMI Male
Cable Length 10M
15M
20M
30M
40M
HDMI Version 2.0
Ethernet Channel No
HDCP Support Version 2.3
Conductor Material Copper, Unspecified Fiber Optic
Maximum Resolution Support 5120 x 2880
Bandwidth 18 Gbps, 5K 60 fps/Hz
Compliance Audio Return Channel (ARC)
HDR
VESA
eARC (10-20M Cables only)
Certifications CMP, FT6, Plenum, REACH, RoHS
*as per Manufacturer
Package Weight 1.4 lb
Box Dimensions (LxWxH) 9.6 x 8.9 x 1.6"
