Item #6POB

Ascendo Audio The6 Passive

On-Wall Loudspeaker - Black/Black Grille - Each
Item #6POB

Ascendo Audio The6 Passive

On-Wall Loudspeaker - Black/Black Grille - Each
$1,550.00
Special Order: Free Shipping!

Overview

The6 PASSIVE ON-WALL delivers dynamic, full-range performance from a compact enclosure designed for flexible immersive theater installations. Its 6.5" time‑coherent coaxial point‑source driver provides controlled directivity and clear imaging, while the shallow cabinet allows easy on‑wall or in‑wall placement. Designed for modern 3D audio systems, The6 combines high sensitivity and strong output capability in a compact footprint.

Does quality need to be a matter of size and budget? This new 6.5"" addition to the CCM speaker series of Ascendo Audio was designed to offer the highest performance ratio to speaker volume.

The same proven two way axi-symmetric point source coaxial technology as the larger CCRM speaker series is employed in a more compact packaging. The The6-P (Previous name: CCM6-P) ideally accompanies the CCM5 and if desired the new SV-12 subwoofer in an all Ascendo Audio budget high-performance system. It can serve as a surround and ceiling speaker in larger home theater systems as well as a music background speaker paired with a subwoofer.

The optional in-wall mounting kit will convert the The6-P into a flexible in-wall speaker.

The high sensitivity of 90dB/w/m paired with 200W RMS power handling lets this speaker be used with lower power receivers or very high-power amplifiers to achieve record SPL for reference level home theater projects. Another major advantage of the The6-P is its shallow depth of only 88 mm.

Details & Specs

Model The6 PASSIVE ON-WALL
Speaker Type 6-1/2” time-coherent point-source coaxial
Principle Vented
Passive / Active Passive
Woofer 6-1/2” woofer
Tweeter 1” soft dome
Recommended ASCENDO Amplifiers AIA2-1404, AIA4-2404, AIA8-2704, AIA8-6004
SPL (Half Space 2π) 111 dB (Cont.) / 122 dB (Peak)
Frequency Range 95 Hz – 20 kHz (-3 dB)
Power Handling 200 W
Efficiency 90 dB / 1 W/m (2π)
Impedance 8 Ω
Directivity Horizontal x Vertical 85° x 85°
Input Terminal 4-conductor Phoenix 12 AWG (3.3 mm²)
Dimensions (W/H/D) Inch (Without Grille) 10-1/4 x 17-5/16 x 3-7/16 in (With grille: 3-11/16 in)
Weight 11.46 lbs (5.2 kg)
Enclosure Internally braced MDF
Mounting 4 x wall mount brackets for horizontal and vertical installation
VESA 100 x 100 mounting points
4 through-holes for direct wall or ceiling mounting
