Item #12POB

Ascendo Audio The12 Passive

On-Wall Loudspeaker - Black/Black Grille - Each
Item #12POB

Ascendo Audio The12 Passive

On-Wall Loudspeaker - Black/Black Grille - Each
$3,550.00
Special Order: Free Shipping!

Overview

The12 PASSIVE ON-WALL steps up output and dynamic capability beyond The10 while maintaining an on-wall form factor suited to high-performance theater systems. Its 12-inch mid-woofer and centrally arranged compression tweeter deliver time-coherent, phase-accurate sound with exceptional impact and efficiency. Designed for screen or surround channel duty in larger cinemas, The12 delivers impressive sound even with lower amplifier power.

The12 PASSIVE ON WALL is positioned perfectly in the ASCENDO monitor lineup, a more dynamic and higher output alternative to the smaller The10 PASSIVE ON-WALL, and a stellar performance value compared to its more expensive, even higher-performance sibling, The12 PRO PASSIVE ON WALL.

The combination of 12-inch mid-woofer and the exclusive, centrally arranged compression tweeter allows for a time-coherent and phase-accurate cinema loudspeaker a cut above the best of the cinema monitors in the market. The highly solid enclosure, elaborately conceived in the light of over 20 years of speaker design experience, ensures extraordinary stable conditions to make parasitic vibrations a thing of the past.

This is time-coherent rendering of all acoustic events at the highest level, and The12 PASSIVE ON WALL’s extremely high efficiency makes it reach incredible volume levels and obtain an impressive cinema sound even with lower amplifier power. A perfect solution as either screen channels, or also surround channels in large home cinema.

Combined with Ascendo Audio's Reference subwoofers you will experience unprecedented spheres of sound.

The12 PASSIVE ON WALL – Impressive sound even with very low amplifier power

Details & Specs

Model The12 PASSIVE ON-WALL
Speaker Type 12” time-coherent point-source coaxial
Principle Vented
Passive / Active Passive
Woofer 12” woofer
Tweeter 3” voice coil diameter, compression driver
Recommended ASCENDO Amplifiers AIA2-2704, AIA4-2404, AIA4-6004, AIA8-6004
SPL (Half Space 2π) 121 dB (Cont.) / 133 dB (Peak)
Frequency Range 95 Hz – 20 kHz (-3 dB)
Power Handling 600 W
Efficiency 99 dB / 1 W/m (2π)
Impedance 8 Ω
Directivity Horizontal x Vertical 85° x 85°
Input Terminal 4-conductor Phoenix 12 AWG (3.3 mm²)
Dimensions (W/H/D) Inch (Without Grille) 15-3/8 x 24-3/16 x 6-7/8 (With grille: 7-1/4)
Weight 47.4 lbs (22.0 kg)
Enclosure Internally braced MDF
Mounting 4 x wall brackets for horizontal and vertical installation
VESA 200 x 100 mounting points
