Anthem STR Integrated Amplifier

Stereo Integrated Amplifier with Anthem Room Correction

Anthem STR Integrated Amplifier

Stereo Integrated Amplifier with Anthem Room Correction
$4,999.99
Select Color Options:

Contact Us

Overview

The revolutionary new STR Integrated Amplifier is based on an entirely new platform. It gives you more control and more power, with more connection options and more advanced technology, in a single, easy-to-use component. It combines the benefits of an advanced pre-amp with the power of a massive amplifier and processor, as well as functions like leading-edge DAC, onboard Anthem Room Correction, customizable bass manager for mono or stereo sub outs, MM and MC phono inputs – far more features than the average integrated amp. And count on Anthem’s digital signal processing innovations to deliver a noticeably higher level of performance realism. The new STR Integrated Amplifier drives all of your entertainment options today, and tomorrow.

  • High-resolution preamplifier section
  • High current, high output amplifier section Amplifier uses 8 bipolar output devices per channel, a toroidal transformer power supply, and Advanced Load Monitoring for 200W at 8 ohms, 400W at 4 ohms, 550W at 2 ohms, all continuous
  • Anthem Room Correction to optimize in-room response
  • Bass management for two subwoofers, in mono or stereo
  • Up-sampling of lower-resolution sources to 24-bit / 192 kHz
  • Asynchronous USB Audio Input supports 32-bit / 384 kHz PCM, and DSD 2.8 / 5.6 MHz sources
  • S/PDIF coaxial and optical, and balanced AES/EBU inputs
  • MM and MC phono, balanced XLR, and single-ended analog inputs
  • Analog Direct mode
  • Graphic Front Panel Display for easy setup navigation
  • Controllable via Ethernet, RS-232, or supplied IR remote

Details & Specs

PHONO PREAMPLIFIER
The phono preamplifier is suitable for moving magnet and high-output moving coil cartridges
Input Impedance 100 Ω (MC), 47 kΩ (MM)
Input Capacitance 270 pF (MM)
Maximum Input (at 1 kHz for <0.1% THD 20 Hz - 20 kHz) 3.6 mV (MC), 37.7 mV (MM)
Gain (default at 1 kHz, user adjustable ± 20 dB) 55 dB (MC), 35 dB (MM)
RIAA Response ± 0.1 dB (20 Hz to 20 kHz)
THD+N (at 1 kHz, 20 Hz - 20 kHz BW, 2 Vrms output) 0.008% (MC), 0.005% (MM)
S/N Ratio (at 1 kHz, IEC-A, 2 Vrms output) 82 dB (MC), 96 dB (MM)
PREAMPLIFIER
Frequency Response
digital-in, 192 kHz 10 Hz - 50 kHz (+0.00, -0.50 dB)
digital-in, 96 kHz 10 Hz - 45 kHz (+0.00, -0.50 dB)
digital-in, 44.1 kHz 10 Hz - 20 kHz (+0.00, -0.03 dB)
analog-in, DSP mode 10 Hz - 40 kHz (+0.02, -0.20 dB)
analog-in, direct mode 10 Hz - 80 kHz (+0.00, -0.10 dB)
THD+N (at 1 kHz, 20 Hz - 20 kHz BW, 2 Vrms output)
digital-in, 44.1 kHz, 0 dBFS 0.0008%
analog-in, DSP mode, 1 Vrms input 0.001%
analog-in, direct mode, 1 Vrms input 0.0020%
SNR (at 1 kHz, IEC-A, 2 Vrms output)
digital-in, 44.1 kHz, 0 dBFS 112 dB
analog-in, DSP mode, 2 Vrms input 110 dB
analog-in, direct mode, 2 Vrms input 120 dB
Maximum Output (<0.1% THD) 2.2 Vrms except analog-direct 3.3 Vrms
XLR Configuration Pin 1: Ground, Pin 2: Normal, Pin 3: Inverted
