Item #C 316BEE V2

NAD OPEN BOX C 316BEE V2-Excellent Condition

Integrated Amplifier
Item #C 316BEE V2

NAD OPEN BOX C 316BEE V2-Excellent Condition

Integrated Amplifier
Was $399.00 $320.00
Save $79
Free Shipping!
Contact Us

Overview

NAD has a distinct reputation for creating some of the best performing budget amplifiers of all time. With the resurgence of vinyl, they decided to update the C316BEE integrated amp's design by including their highly acclaimed RIAA phono stage. This sophisticated circuit combines low noise with high overload margins to eliminate noise and distortion. RIAA equalization is extremely accurate (a rarity at this price) and there is even an infrasonic filter to reject airborne vibrations that can cause parasitic feedback.

Proven Technology Enhanced by Innovation

NAD’s PowerDrive Circuit has been proven to offer a remarkable combination of high current drive needed for complex loudspeaker loads, and high levels of undistorted dynamic power. By monitoring the precise operating condition of the power amplifier, PowerDrive uses this intelligence to automatically optimize the power supply settings for uniformly low distortion and maximum power in the real world of music listening. As featured in our top Masters Series models, PowerDrive uses a complex ‘analog computer’ to determine the optimal settings. For the C 316BEE V2, NAD utilized PowerDrive S, a clever computation circuit requiring fewer parts at a much lower cost without any reduction in effectiveness. For short term peaks of 5 milliseconds, the C 316BEE V2’s undistorted peak power is >110W into 8 Ohms, 190W into 4 Ohms, and 270W into 2 Ohms. All the hallmarks of NAD technology are present, from the generously sized toroidal power transformer and low ESR smoothing capacitors, to the multiple regulated secondary supplies, to the heavy-duty discrete output transistors, the C 316BEE V2 is every bit as refined and sophisticated as other NAD amplifiers.

Simplicity

While the C 316BEE V2 has everything necessary for musical enjoyment, it is refreshingly limited to the essentials: six inputs, one set of speakers, a headphone jack, and full-function remote control. It has a compact size and a handsome yet understated exterior. It is essential NAD.

Value

NAD is confident that the C 316BEE V2 will set new benchmarks for performance, both measured and audible, at this affordable price point. Unless you have power-hungry speakers, listen at dangerously loud levels, or have a very large room, the C 316BEE V2 will be the amplifier for you. Fundamental specifications for noise, distortion, power, stereo separation, and volume control tracking, are all class-leading and would be impressive on an amplifier costing many times its modest price. While its bells and whistles may not be as extensive as more expensive offerings, the C 316BEE V2 is far from a “stripped down” product. With six line level inputs, including an MM Phono Input, full IR remote control, defeatable tone controls, and a front panel media player input for a phone or tablet, the C 316BEE V2 is fully equipped to be the control center for a high-performance music system. The sonic result of this high technology is a relaxed and inviting sound that digs out the subtle details in your favorite recordings and presents them across a panoramic stereo sound stage. The impressive dynamic power reserves make the C 316BEE V2 sound both articulate and alive. The silent background and low distortion gives a sense of solidity and presence to your music and brings out the best your loudspeakers have to offer.

Details & Specs

LINE IN/HEADPHONE OUT

THD (20 Hz – 20 kHz) - <0.03 % in 300 ohms at 2 V out

Signal-to-Noise Ratio - >100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)

Frequency response - ±0.3 dB (20 Hz - 20 kHz)

Output impedance - 68 ohms

LINE IN/SPEAKER OUT

Continuous output power into 8 ohms and 4 ohms - 40W (ref. 20 Hz-20 kHz at rated THD, both channels driven)

THD (20 Hz – 20 kHz) - <0.03 % (250 mW to 40 W, 8 ohms and 4 ohms)

Signal-to-Noise Ratio -

  • >95 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
  • >97 dB (A-weighted, 500 mV input, unity gain in 32 ohms)

Clipping power (at 1 kHz 0.1 % THD) -

  • >45 W in 8 ohms
  • >60 W in 4 ohms

IHF dynamic power -

  • 8 ohms: 90 W
  • 4 ohms: 120 W
  • 2 ohms: 170 W

Damping factor - >200 (ref. 8 ohms, 1 kHz)

Frequency response -

  • ±0.3 dB (20 Hz - 20 kHz, Tone Defeat ON)
  • Treble: ± 5dB at 10 kHz
  • Bass: ± 8 dB at 100 Hz

Channel separation - >70 dB (1 kHz)

Maximum input level - 4.3V (1 kHz THD 0.1%)

Input sensitivity (for 40 W in 8 ohms) - 200 mV

Standby power - <0.5 W

PHONO IN/SPEAKER OUT

THD (20 Hz – 20 kHz) - <0.03 % (1 W to 40 W, 8 ohms and 4 ohms)

Signal-to-Noise Ratio - >75 dB with IHF MM cartridge (A-weighted, ref. 5mV input 1 kHz and 1W output in 8 ohms)

Frequency response (RIAA deviation) - ±0.3 dB (20 Hz - 20 kHz, Tone Defeat ON)

Note: The RIAA response is consistent with a pre-emphasis that is rolled off at 50kHz by a second-order filter, such as used in Neumann cutting lathes.

Maximum input level - 71 mV (1 kHz THD 0.1%)

Input sensitivity (for 40 W in 8 ohms) - 2.95 mV

Dimensions (W x H x D) - 17 1/8 x 3 9/16 x 11 1/4 inches
