Kaleidescape Terra Prime Movie Server

Movie Server - HDD

Kaleidescape Terra Prime Movie Server

Movie Server - HDD
From $15,995.00
Select Internal Storage

Contact Us

Overview

Terra Prime movie servers feature an all-new board design, faster processing power, and a faster network. Offering faster downloads than its predecessor, with the highest capacity. Terra Prime adds increased performance and storage capabilities.

Terra Prime stores movies, TV series, and concerts on an array of enterprise-class hard drives. Content stored on the movie server is played back on Strato players.

Made in the USA, Kaleidescape movie servers are custom designed and manufactured for reliable, premium performance.

Kaleidescape’s operating system (kOS) is custom developed, managed, and controlled internally, with automatic updates, providing the best experience of any movie server on the market.

Terra Prime movie servers can download a Kaleidescape high-bitrate 4K movie in as little as eight minutes, with properly configured 2.5 Gbit/sec capable networking, hardware, and ISP.

Key Features

  • Next-generation movie server with high capacity
  • 2.5 Gigabit Ethernet
  • Enterprise-class hard disk drives
  • Storage options for approximately 1,450 (88TB), 800 (48TB), 350 (22TB), or 130 (8TB) 4K movies
  • Downloads a Kaleidescape high-bitrate 4K movie in as little as eight minutes
  • Kaleidescape 4K movies have lossless audio and reference video
  • All movies are stored securely and protected by cloud backup
  • Distributes up to five simultaneous playback streams (compact)
  • Distributes up to 10 simultaneous playback streams (full-size)
  • Movies can be downloaded on up to five systems; perfect for multiple residences
  • Terra movie servers enable large configurations
  • Up to four Terra servers can be combined for more storage
  • Custom rack mounts sold separately

Details & Specs

Model Terra Prime HDD
Shared Specifications
Movie Server Downloads Kaleidescape high-bitrate 4K movies in as little as 8 minutes
Compact serves up to 5 simultaneous playbacks of Kaleidescape 4K movies
Full-size serves up to 10 simultaneous playbacks of Kaleidescape 4K movies
Network 2.5 Gigabit Ethernet (recommended)
1 Gigabit Ethernet (minimum)
Other Connection USB 3.0 (reserved)
Environment Operating: 41 to 95°F (5 to 35°C)
Storage: -4 to 140°F (-20 to 60°C)
Relative humidity: 20 to 80% (operation), 5 to 90% (storage)
Maximum operating altitude: 10,000ft (3,048m)
Ventilation Airflow:
Full Size - 10 CFM (17 m3/hr) max
Compact - 5 CFM (8.4 m3/hr) max
Minimum 1" (2.5cm) space at the front
Minimum 2" (5cm) space at the rear
Certifications CSA 62368-1
IEC 62368-1
FCC CLASS B
CE
RoHS Compliant
Full Size - 88 & 48 TB
Dimensions (WxHxD) 17.0 x 3.5 x 10.0"
43.2 x 8.9 x 25.4 cm
Weight 15.4 lb (7.0 kg) with no drives installed
21.6 lbs (9.8 kg) with four hard drives
Fan & Drive Noise Typical: 29 dB(A)
Power Max consumption: 48W
Typical: 43W
External power adapter:
2.6 x 1.4 x 6.5" (6.6 x 3.5 x 16.5 cm)
150W with detachable line cord
100-240V, 50-60Hz universal input
12VDC @ 12.5A
Storage Four removable 22TB or 12TB hard drives (88TB or 48TB total)
88TB configuration stores:
~1,450 Kaleidescape high-bitrate 4K movies
~2,300 HD movies
~13,500 SD movies
48TB configuration stores:
~800 Kaleidescape high-bitrate 4K movies
~1,300 HD movies
~7,200 SD movies
Rack Mount (sold separately) Rack shelf available for mounting one unit in a 19" rack
2RU space
Compact - 22 & 8 TB
Dimensions (WxHxD) 7.87 x 1.52 x 14.33"
20.0 x 3.9 x 36.4 cm
Weight 7.2 lbs (3.3 kg)
Fan & Drive Noise Typical: 25 dB(A)
Power Max consumption: 29W
Typical: 24W
External power adapter:
2.6 x 1.4 x 6.5in (6.6 x 3.5 x 16.5 cm)
150W with detachable line cord
100-240V, 50-60Hz universal input
12VDC @ 12.5A
Storage One integrated 22TB or 8TB hard drive
22TB configuration stores:
~350 Kaleidescape high-bitrate 4K movies
~600 HD movies
~3,300 SD movies
8TB configuration stores:
~130 Kaleidescape high-bitrate 4K movies
~220 HD movies
~1,200 SD movies
Rack Mount (sold separately) Rack shelf available for mounting one or two units in a 19" rack
1RU space
