Features & Technology
Metamaterial Absorption Technology
First up is the addition of KEF’s revolutionary sound absorption technology called Metamaterial Absorption Technology, or “MAT” for short. MAT was first implemented in their LS50 speaker in 2020 and then expanded to some of their high-end speakers, like their Blades and R Series. And now, MAT has trickled down into all eight new models in the Q Series for the first time.
MAT is essentially a maze-like structure with intricate channels that absorb a specific frequency, acting as an “acoustic black hole,” absorbing 99% of the unwanted sound that comes from the rear of the tweeter. With MAT, you get a tweeter that measures flatter and has a more natural and pure sound quality.
Including MAT in the new Q series is a pretty big deal. We visited the KEF USA facility back in 2022 and were impressed with the dedication the engineers and their entire team have to push the state of the art of sound to its limits. They have put a ton of time and effort into their research and development of all of their technology and, most recently, MAT. So it would make sense to see MAT in only their high-end speakers to justify the cost of developing it. However, in typical KEF fashion, they’ve found a way to trickle down this tech into the affordable Q Series to give them an incredible sound that punches well above their weight.
Uni-Q Driver
Another part of these new Q Series speakers is the 12th generation Uni-Q driver array in each model. Once again, KEF has utilized its own in-house knowledge and state-of-the-art simulation and analysis tools to create a driver that pairs with the MAT for better performance. Specifically, the conical waveguide that couples the tweeter dome to the metamaterial absorber has been specially designed for the driver based on its depth. Plus, they re-engineered the tweeter gap damper which strategically places two rings of porous material to tame the resonances and imperfections, which will give the sound more clarity and detail. In addition, they redesigned the entire tweeter motor system by increasing the rear chamber vent area behind the tweeter by 250% to allow more sound to reach the MAT, allowing it to be even more effective.
In the Q11, Q7, Q6, and Q Concerto, KEF has included a flexible decoupling chassis used in their flagship Blade and reference models. This works by decoupling the midrange motor from the Uni-Q chassis, therefore dissipating its vibration before it can travel to the cabinet and add any unwanted coloration to the sound. This is all super cool tech that, to us, really brings these speakers up to a whole new level!
By having the tweeter sitting inside the mid/bass driver, KEF gives you what mimics a point source, which many people consider speakers' holy grail. This is one of our favorite reasons we love the Uni-Q driver tech so much is its ability to eliminate a “sweet spot” and disperse the sound evenly throughout the room for everyone to enjoy due to it being a single-point source design.
